SM-OT005E 5-Function Electric Operating Table
Product Overview
The SM-OT005E Electric Operating Table is a professional solution for surgeries on various human body parts in hospital operating rooms. It combines the versatility of a comprehensive operating table with unique advantages—such as a detachable, easy-adjust footboard (ideal for urology procedures) and a highly translatable, X-ray permeable tabletop. All key tabletop movements (translation, back lifting, forward/backward tilting, left/right tilting, up/down lifting) are powered by electric push rods, controlled via buttons for safe and reliable operation. It is also compatible with C-arm X-ray machines, meeting the needs of intraoperative imaging and multi-specialty surgeries.
Core Advantages & Features
- Stable & Precise Performance
Equipped with high-precision medical micro-motors and electric push rod mechanical structures, ensuring superior rigidity, uniform running speed, accurate patient positioning, and long-term durability.
- Independent Power for Key Functions
Lifting, translation, head/foot tilting, left/right tilting, and back lifting are each driven by an independent power system, avoiding mutual interference and ensuring smooth operation.
- Enhanced Surgical Flexibility
- Built-in 120mm waist bridge for optimal patient posture during complex surgeries.
- 300mm large electric horizontal tabletop travel: Adjust positions easily without moving the patient, supported by high-precision linear guide rails for smoothness.
- Premium & Hygienic Materials
- Frame: High-quality nickel-chromium stainless alloy steel; side rails: 304 stainless steel with surface sandblasting and electrolytic oxidation (easy to clean and disinfect).
- Base shell: High-quality stainless steel, meeting strict operating room hygiene standards.
- Comfortable & Practical Mattress
One-piece high-sealing sponge mattress (soft texture) with memory recovery function—reduces local pressure on patients. Seamless, waterproof, anti-static, and removable for easy cleaning.
Technical Specifications
| Project | Parameter |
|---|---|
| Operating table length | 1980±10mm |
| Total width of operating table | 510mm (without side rails); 560mm (with side rails) |
| Table height (without leather pad) | Min 670±20mm; Max 920±20mm |
| Headboard adjustment | Folds up 40°±2°, folds down 90°±2°; detachable |
| Back panel angle | Folds up 60°±2°, folds down 25°±2° |
| Table forward/backward tilt | Forward 20°±2°; Backward 20°±2° |
| Table left/right tilt | Left 22°±2°; Right 22°±2° |
| Table translation | 300±5mm |
| Leg angle (split type) | Folds outward 90°±2°, folds upward 10°±2°, folds downward 90°±2° |
| Built-in waist bridge | 120mm |
| Power supply | Voltage: 220V±22V 50Hz+1Hz; Operating power: 400W; Standby power: 10W |
| Safe load | 200kg |
| Deadweight | 200kg |
Ideal Application Scenarios
Suitable for chest, abdomen, brain, ophthalmology, otolaryngology, obstetrics and gynecology, urology, and orthopedics surgeries—perfect for hospitals, clinics, and surgical centers requiring a versatile, high-performance operating table.
